Speed: 33, 45 (manual speed change)
Principle: Belt drive
Speed variance: 33: 0.60%, 45: 0.50%
Wow & Flutter: 33: 0.19%, 45: 0.17%
Platter: 300 mm glass with felt mat
Main bearing: Brass with teflon plate
Tonearm: 8.6” aluminium
Effective arm length: 218.5 mm
Output voltage at 1000 Hz, 5cm/sec: 5 mV
Frequency response: 20-20.000 Hz ± 1.5 dB
Stylus type: Spherical
Internal inductance: 450 mH
Recommended load resistance: 47 kOhm
Recommended load capacitance: 200-500 pF
Cartridge weight: 19g
Overhang: 18.5 mm
Effective tonearm mass: 6.0 g
Counterweight for mass: 2 - 5.0 g
Tracking force, recommended: 1.75g (17.5mN)
Power consumption: 4.5 Watt max
Dimensions: 500 x 120 x 400 mm (WxHxD)
Weight: 4.5 kg net
|
