Marantz Model M1 Wireless 2 Channel Streaming Amplifier with 100W eARC HEOS Built-in

Marantz Model M1 Wireless 2 Channel Streaming Amplifier with 100W eARC HEOS Built-in

Introducing the Marantz Model M1 Wireless Streaming Amplifier: Uniting Style and Power

Experience true hi-fi sound in a sleek and unobtrusive package with the Marantz Model M1 Wireless Streaming Amplifier. This compact yet feature-packed device delivers powerful audio performance while seamlessly blending into any environment.

Stream with Superior Quality

Unlock the potential of your music collection with the Marantz Model M1. Simply pair it with your choice of speakers to enjoy superb streaming capabilities. Its versatile network streaming functionality ensures top-notch audio quality every time.

Compact Yet Mighty

Despite its small footprint, the Marantz Model M1 packs a punch. Boasting 100 watts per channel, it effortlessly drives a wide range of speakers, making it suitable for any room size. Plus, with a subwoofer output, you can further enhance your audio experience with deep, rich bass.

Elevated Listening Experience

Tuned by Marantz's Sound Master, the Model M1 features Marantz Musical Digital Filtering technology. This advanced digital filtering technology enhances tonality and detail, allowing you to appreciate every nuance of your favorite tracks.

Seamless Connectivity

With Bluetooth, AirPlay 2, Wi-Fi, Internet radio, and DLNA capabilities, the Model M1 offers a complete networking experience. Connect all your devices effortlessly and access thousands of Internet radio stations and streaming services like Spotify Connect.

Multi-Room Audio Made Easy

Thanks to HEOS built-in technology, the Marantz Model M1 seamlessly integrates into your multi-room audio setup. With dual-band Wi-Fi connectivity, you can link up to 32 HEOS units, ensuring every corner of your home is filled with exceptional sound.

Effortless Control

Manage your music effortlessly with the HEOS app, available for iOS, Android, and Amazon Kindle devices. Stream your stored music, access Internet radio, and enjoy popular streaming services like Spotify, Tidal, and Deezer—all from one convenient app.

Versatile Connectivity Options

In addition to streaming capabilities, the Model M1 offers versatile connectivity options. Connect your TV via HDMI (eARC) for enhanced sound quality, or use the digital optical input for CD/DVD/Blu-ray players and gaming consoles. Analog RCA phono inputs cater to older devices without digital outputs.

Voice Control Integration

Compatible with Amazon Alexa, Google Assistant, and Siri devices, the Marantz Model M1 offers seamless voice control. Simply download the HEOS Home Entertainment Skill app and enjoy hands-free operation with your favorite voice assistant.

Experience discreet yet powerful music throughout your home with the Marantz Model M1 Wireless Streaming Amplifier.

Technical Specifications

• Power Amplifier Rated output & THD (8 ohm)100 W+100 W (8 Ω, THD 0.05%)
• Power Amplifier Rated output & THD (4ohm)125 W + 125 W (4Ω/ohms, 1 kHz, T.H.D. 0.05%)
• Frequency Response20 Hz to 20 kHz : ±1 dB
• Connected loudspeaker Impedance4 – 16 Ω/ohms

• Loudspeaker Binding Posts4-way binding posts
• Digital InputsHDMI (eARC), TOSLINK
• Analog InputsRCA L/R
• Subwoofer OutRCA Mono

• Channel AssignmentsStereo (Default), Dual Mono
• Volume Limit80-100%
• Balance-15dB to +15dB
• Adjustable High Pass / Low Pass Filters40-250 Hz / 40-120 Hz
• EQBass, Treble -5dB to +5dB
• Sound ModesStereo, Direct, Virtual, Dialog Enhancer, Night Mode
• TV Sound GroupingYes

• DecodingDolby Digital +, Dolby Digital, LPCM, DSD
• Stereo PCM / Multi-channel PCMYes / Yes
• Stereo File Formats (HEOS network share or USB)WMA: up to and including 192 kbps, AAC & MP3: up to and including 320 kbps, WAV, ALAC, FLAC: up to and including 24-bit/192kHz, DSD: 2.8 MHz, 5.6MHz

• Bluetooth ReceiveBT 5.X
• Bluetooth TrasmitNo
• AirPlayAirPlay 2
• SpotifySpotify Connect

• Music Services Supported (HEOS®, subject to change and local availability)Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, Tidal, Tidal HiRes, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, QPlay, SoundCloud.
• Music stored on mobile deviceYes (iOS, Android or Kindle Fire)
• NAS (Network Attached Storage)Network share
• USB Storage Device PlaybackYes (FAT32, NTFS formatted drives)

• Wired ConnectivityEthernet
• Wireless ConnectivityDual band, 802.11 a/b/g/n/ac
• IR Input3.5mm
• IR LearningYes
• Control System Compatibility via TCP/IPCreston, Control4, AMX
• HEOS® AppiOS, Android, Kindle Fire

• Product ColorBlack
• User InterfaceVolume up/down, Play / Pause, Multi colored LED status indicator, Connect button (rear), Bluetooth button (rear)
• Dimensions (W x D x H) Inches9.41 x 3.31 x 8.54
• Dimensions (W x D x H) mm239 x 84 x 217
• Weight (lbs)4.84
• Weight (kg)2.2
